Pneuparts.com is a website that specializes in selling pneumatic components, such as fittings, hoses, cylinders and valves. One of the product categories found on the website is push-in fittings.

Push-in fitting

A push-in fitting is a type of fitting used to connect a pneumatic hose to another component. This type of compressed air fitting is easy to install and remove without the need for tools. This makes the fittings suitable for quick replacement or easy relocation of components in a pneumatic system.

Push-in fittings are designed with a clamping mechanism that clamps the hose into the fitting without the use of lock washers or other fasteners.
This makes changing hoses or changing the routing of a pneumatic system quick and easy.

The push-in fittings are equipped as standard with an automatic seal, which prevents the leakage of the medium even if the hose is released from the fitting. This increases the reliability and safety of the pneumatic system.

The push-in fittings at pneuparts.com are available in different materials, such as brass, stainless steel, aluminum and polyamide. This makes them suitable for various applications, from food and cooling water to air and vacuum, as they have a low pressure drop. The fittings are also chemical resistant, making them suitable for applications involving acid or alkali.

These couplings are available in different sizes, from very small to large, so there is a suitable fitting for every application. Moreover, they are also available in different connection sizes, such as G1/8, G1/4, G3/8, G1/2 and G3/4.

A suitable push-in fitting can be found for any specific application or pneumatic system. Some examples of possible versions are:

• T Push-in fitting (For splitting compressed air roads)
• Elbow Push-in fitting (For a 90° or 45° angle)
• Y-Push-in fitting (For splitting compressed air roads)
• X Push-in fitting (For splitting, as well as for straight-through course of compressed air roads)
• Push-in connector, reducing (Connecting hoses of different size together)
• Extension piece
• Speed control valve
• etc.

Push-in fittings are versatile in their applications and can be used in a wide range of industrial sectors, including automotive, food and beverage, pharmaceutical and mechanical engineering. But are also used in automation applications, such as robotics and manufacturing equipment, in pneumatic systems for conveyors and packaging machines, these fittings are common.

In short, Pneuparts.com offers a wide range of push-in fittings for different applications and sizes, made of different materials, which are easy to install and remove without tools. Push-in fittings can be used in a wide range of industrial applications and in addition to applications with compressed air, they are also suitable for use in vacuum systems and with chemicals.

> See all of our push-in fittings

How to attach a push-in coupling?





1. Make sure the hose is clean and dry before attaching the coupling;
2. Place the coupling in the correct position on the pipe. The coupling should be properly aligned with the pipes to prevent leakage;
3. Attach the coupling to the pipes by pressing the hose into the coupling. Make sure the coupling is securely attached;
4. When the coupling is attached, check that there is no leakage by testing the pipes with air pressure.

Please note that depending on the type of coupling, there may be different steps to confirm it.
