Pneuparts filter regulator, M5 x 0.8, 0.5 - 7 bar
Article number: FRU5
Article number: FRU5
 | Pneuparts new series filter regulators | |
| Pneuparts new series - brackets | |
 | 3D-CAD-file FRU5 |
excl. VAT incl. VAT
| Pneuparts new series filter regulators | |
| Pneuparts new series - brackets | |
| 3D-CAD-file FRU5 |
Media:
Compressed air, neutral gases
Operating pressure:
0.5 - 10 bar
Temperature range:
-5 ° C to + 60 ° C
To belong:
Pressure gauge, L-type mounting bracket
All statements are intended as non-binding guidelines! We are not liable for data selection not confirmed in writing. Pressure data, unless stated otherwise, relate to liquids from group II at +20 C.
TECHNICAL DATA | |
|---|---|
| Thread | M5 |
| Pressure regulation area | 0.5 - 7 bar |
| Workload | 0.5 - 10 bar |
| Filter porosity [Micrometer] | 5 |
| Amount of condensate | 3.5 cm³ |
| Version | Polycarbonate bowl |
| Flow | - |
| Weight | grams each |
| Commodity code | 84811005 |
