Straight push-in coupling 3/8 "(9.52 mm) - 3/8" (9.52 mm), food (EPDM seal)

Materials:

Housing and release ring: Polymer (POM, FDA certified)

Locking Claw: Stainless Steel

Seals: EPDM (FDA certified)



Temperature range:

0°C to +65°C



Operating pressure:

-0.95 to 11/16 bar (Ø 3/8", 1/2", 10 mm & 12 mm: max. 11 bar)*



Media:

Oil-free compressed air, water, liquid food, non-hazardous gases and liquids (not mineral oils), mild chemicals



Approvals:

NSF / ANSI 61, materials compliant with FDA



Advantages:

Available for metric and imperial hoses

G-threaded, R-threaded and NPT threaded available

Compatible with numerous other manufacturers



*At temperatures >20°C, calculate operating pressure with these correction factors: 30°C: 0.88 - 40°C: 0.77 - 50°C: 0.69 - 65°C: 0.63, example: 50°C, operating pressure = 16 bar * 0.69 = 11 bar

All statements are intended as non-binding guidelines! We are not liable for data selection not confirmed in writing. Pressure data, unless stated otherwise, relate to liquids from group II at +20 C.
